UL891 SWITCHBOARDS

Gavan-Graham - electrical products manufacturer in New Jersey offers a wide variety of custom switchboards specifically designed to fit your needs.  Each switchboard is crafted with the finest components to ensure a strong and reliable system.



FEATURES



- All switchboard designs are UL891 Designed and Labeled



-Built to NEMA 1, 3R, 12, 4 and 4X requirements



-Ability to incorporate a variety of components including MCCB’s, Bolted Pressure Switches and fusible switches.  We work with most major circuit breaker manufactures to meet specification requirements



-Up to 6000a maximum bus rating available



-1000a per square inch Silver Plated Copper bus standard.  Options for Tin Plated, as well has 700a/800a per square inch available to meet local codes



-65kA standard bus bracing.  Optional 100 or 200 kA/C



-Insulated bus available



-AC and DC voltages available



-Front and rear accessible

-Microprocessor-based metering and monitoring devices available.



-Utility metering provisions



-Transient voltage surge suppression optional



-Custom Busway and transformer connections for matching up to any manufacturer’s equipment
